The GW8318 is an advanced 8-channel capacitive sensor designed specifically for SAR (Specific Absorption Rate) applications. Operating at a high-performance level with a voltage input of 1.8V, this intelligent and smart sensor excels in sensing user presence at multiple distances, thereby significantly enhancing SAR functionalities.

The primary purpose of the GW8318 is to detect the presence of users at varying distances, enabling the optimization of Radio Frequency (RF) emission power in the presence of the human body. The GW8318 empowers manufacturers of portable electronic devices with electromagnetic radiation sources to comply with stringent emission regulations and SAR standards, resulting in notable performance advantages.

The GW8318 communicates its data through the I2C serial bus, which is compatible with 1.8V host control. This communication allows for reporting body detection/proximity and facilitates easy adjustment of parameters. When proximity is detected, the NIRQ output is activated, offerin
